Pool Lighting
Zodiac NL are nicheless LED projectors that fit standard 1½" nozzles, offered at 6 W, 12 W and 24 W in white and RGBW. Compared with 300 W halogen they deliver up to 90% energy savings and up to 10 times longer life; they run on 12 V AC, have a 3 m cable and are Fluidra Pool compatible.
NL 6RGBW · RGBW · 6 W · IP68
Birden fazla ürünü listenize ekleyip hepsi için tek seferde teklif isteyebilirsiniz. Tek ürün için hemen teklif isteyin.
| Mounting | Nicheless, 1½" nozzle / wall passage |
|---|---|
| Power | 6 W · 12 W · 24 W |
| Light | White (BW) or RGBW: 9 colours + 5 programmes |
| Supply | 12 V AC |
| Cable | 3 m |
| Energy saving | Up to 90% vs 300 W halogen |
| Compatibility | eXO® iQ · Hydroxinator® iQ · Command Connect · Fluidra Pool |
Values by order code
| Order code | ||||||
|---|---|---|---|---|---|---|
| Power (W) | 6 | 12 | 24 | 6 | 12 | 24 |
| Light type | RGBW | RGBW | RGBW | BW | BW | BW |
| Order code | Variant description | Certifications |
|---|---|---|
| WT000233 | NL 6RGBW · RGBW · 6 W | IP68 |
| WT000234 | NL 12RGBW · RGBW · 12 W | IP68 |
| WT000235 | NL 24RGBW · RGBW · 24 W | IP68 |
| WT000236 | NL 6BW · White · 6 W | IP68 |
| WT000237 | NL 12BW · White · 12 W | IP68 |
| WT000238 | NL 24BW · White · 24 W | IP68 |
Zodiac NL are nicheless LED projectors that fit standard 1½" nozzles, offered at 6 W, 12 W and 24 W in white and RGBW. Compared with 300 W halogen they deliver up to 90% energy savings and up to 10 times longer life; they run on 12 V AC, have a 3 m cable and are Fluidra Pool compatible.
Zodiac NL LED lights use high-quality LED technology to provide a powerful, energy-saving and easy-to-install pool lighting solution. Thanks to "nicheless" mounting the light fits quickly into any pool type (liner/PVC, reinforced concrete, polyester etc.) via a standard 1½" wall passage, with no special niche needed during construction. For example, three 12 W NL LED lights with a total consumption of 27 W can replace a classic 300 W projector.
RGBW models provide 9 fixed colours and 5 multicolour lighting ambiances (programmes); a separate white LED gives pure white and pastel tones. They are 100% compatible with the Zodiac eXO® iQ smart salt chlorinator, Hydroxinator® iQ and the Command Connect cabinet; when controlled via the Command Connect cabinet they can be managed from the Fluidra Pool app. Cable length is 3 metres.
Get a quote for Zodiac NL Nicheless LED Lights
We select equipment together based on pool volume, turnover time and plant-room conditions.
We bring filters, pumps, chemicals and accessories together in a single quote.
Our engineering team answers your questions on model selection, capacity and compatibility.
We support you through installation, commissioning and periodic maintenance.
