Pool Lighting
LumiPlus FlexiMini Connect are compact pool LED lamps for steps and walls: the steps series delivers 300–450 lm and the wall series 800–900 lm. Available in white, warm white, tunable white, RGB and RGBW, they run on 12 V AC, come with a 2.5 m cable and are controlled with LumiPlus Connect and the Fluidra Pool app.
Steps · White · IP68, EU 2019/2015
Birden fazla ürünü listenize ekleyip hepsi için tek seferde teklif isteyebilirsiniz. Tek ürün için hemen teklif isteyin.
| Supply | 12 V AC |
|---|---|
| Steps series | 3,5 – 5 W · 300 – 450 lm |
| Wall series | 7 – 10 W · 800 – 900 lm |
| Light options | White, warm white, tunable white, RGB, RGBW |
| Cable | 2,5 m |
| Control | LumiPlus Connect 76290 |
Values by order code
| Order code | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Power (W) | 3.5 | 3.5 | 3.5 | 4 | 5 | 7 | 7 | 7 | 10 |
| Apparent power (VA) | 4.5 | 4.5 | 4.5 | 6 | 7.5 | 10.5 | 10.5 | 10.5 | 15 |
| Luminous flux (lm) | 450 | 450 | 450 | 300 | 400 | 900 | 900 | 900 | 800 |
| Energy class | D | D | D | G | F | D | D | D | F |
| Order code | Variant description | Certifications |
|---|---|---|
| 76602 | Steps · White | IP68, EU 2019/2015 |
| 76602WW | Steps · Warm white | IP68, EU 2019/2015 |
| 76602TW | Steps · Tunable white | IP68, EU 2019/2015 |
| 76602M | Steps · RGB | IP68, EU 2019/2015 |
| 76602MW | Steps · RGBW | IP68, EU 2019/2015 |
| 76603 | Wall · White | IP68, EU 2019/2015 |
| 76603WW | Wall · Warm white | IP68, EU 2019/2015 |
| 76603TW | Wall · Tunable white | IP68, EU 2019/2015 |
| 76603MW | Wall · RGBW | IP68, EU 2019/2015 |
LumiPlus FlexiMini Connect are compact pool LED lamps for steps and walls: the steps series delivers 300–450 lm and the wall series 800–900 lm. Available in white, warm white, tunable white, RGB and RGBW, they run on 12 V AC, come with a 2.5 m cable and are controlled with LumiPlus Connect and the Fluidra Pool app.
FlexiMini is the compact version of the Flexi system, designed for more discreet installations; it is ideal for steps, seating benches, spas and small pool walls. Connect lamps give full control of the light: the steps series draws 3.5–5 W (4.5–7.5 VA) and the wall series 7–10 W (10.5–15 VA). Colour temperatures are white 5700 K, warm white 3000 K and tunable white 2500–6000 K.
The lamps are controlled through the LumiPlus Connect controller (76290) and the Fluidra Pool app, and optionally with a Connect remote. They are installed in concrete, liner and fibreglass pools with the FlexiMini Pure, FlexiMini Niche, Nozzle L, Nozzle S and Pipe fixing systems.
