Pool Lighting
FlexiMini Pure (concrete/polyester and liner), Niche, Nozzle L, Nozzle S and Pipe fixing systems for FlexiMini lamps. Frames from Ø96 mm to Ø161 mm are offered in white, beige, grey, anthracite and stainless steel and are mounted on a mini niche, nozzle or wall sleeve.
FlexiMini Pure · concrete/polyester · White
Birden fazla ürünü listenize ekleyip hepsi için tek seferde teklif isteyebilirsiniz. Tek ürün için hemen teklif isteyin.
| FlexiMini Pure (concrete/polyester) | Ø115 × 6 mm · niche 77575 / nozzle 77576 |
|---|---|
| FlexiMini Pure (liner) | Ø119 × 9 mm · niche 77578 |
| FlexiMini Niche | Ø161 × 15.5 mm · mini niche 06967 / 00369 / 49828 |
| Nozzle L | Ø132 × 22 mm · nozzle Ø ≤ 116 mm |
| Nozzle S | Ø96 × 19.5 mm · nozzle Ø ≤ 90 mm |
| Pipe | Ø96 × 12 mm · pipe / wall sleeve |
Values by model
| Model | ||||||
|---|---|---|---|---|---|---|
| Frame size (mm) | Ø115 × 6 | Ø119 × 9 | Ø161 × 15.5 | Ø132 × 22 | Ø96 × 19.5 | Ø96 × 12 |
| Compatible niche / nozzle | 77575 / 77576 | 77578 | 06967 / 00369 / 49828 | Ø ≤ 116 | Ø ≤ 90 | 15661 |
| Order code | Variant description | Certifications |
|---|---|---|
| 77574 | FlexiMini Pure · concrete/polyester · White | — |
| 77574CL090 | FlexiMini Pure · concrete/polyester · Beige | — |
| 77574CL129 | FlexiMini Pure · concrete/polyester · Grey | — |
| 77574CL144 | FlexiMini Pure · concrete/polyester · Anthracite | — |
| 77574CLSS | FlexiMini Pure · concrete/polyester · Stainless steel | — |
| 77577 | FlexiMini Pure · liner · White | — |
| 77577CL090 | FlexiMini Pure · liner · Beige | — |
| 77577CL129 | FlexiMini Pure · liner · Grey | — |
| 77577CL144 | FlexiMini Pure · liner · Anthracite | — |
| 77577CLSS | FlexiMini Pure · liner · Stainless steel | — |
| 74392 | FlexiMini Niche · White | — |
| 74392CL090 | FlexiMini Niche · Beige | — |
| 74392CL129 | FlexiMini Niche · Grey | — |
| 74392CL144 | FlexiMini Niche · Anthracite | — |
| 74392CLSS | FlexiMini Niche · Stainless steel | — |
| 74393 | FlexiMini Nozzle L · White | — |
| 74393CL090 | FlexiMini Nozzle L · Beige | — |
| 74393CL129 | FlexiMini Nozzle L · Grey | — |
| 74393CL144 | FlexiMini Nozzle L · Anthracite | — |
| 74393CLSS | FlexiMini Nozzle L · Stainless steel | — |
| 74394 | FlexiMini Nozzle S · White | — |
| 74394CL090 | FlexiMini Nozzle S · Beige | — |
| 74394CL129 | FlexiMini Nozzle S · Grey | — |
| 74395 | FlexiMini Pipe · White | — |
| 74395CL090 | FlexiMini Pipe · Beige | — |
| 74395CL129 | FlexiMini Pipe · Grey | — |
| 74395CL144 | FlexiMini Pipe · Anthracite | — |
FlexiMini Pure (concrete/polyester and liner), Niche, Nozzle L, Nozzle S and Pipe fixing systems for FlexiMini lamps. Frames from Ø96 mm to Ø161 mm are offered in white, beige, grey, anthracite and stainless steel and are mounted on a mini niche, nozzle or wall sleeve.
FlexiMini Pure is a minimalist frame that enhances a modern look: the Ø115 × 6 mm frame (77574) is used with the 77575 concrete pool niche and 77576 polyester pool nozzle, and the Ø119 × 9 mm frame (77577) with the 77578 liner pool niche. The FlexiMini Niche frame (Ø161 × 15.5 mm) fits the 06967, 00369 or 49828 mini niches.
The Nozzle L frame (Ø132 × 22 mm) fits nozzles of Ø116 mm or smaller and the Nozzle S frame (Ø96 × 19.5 mm) nozzles of Ø90 mm or smaller. The Pipe frame (Ø96 × 12 mm) fits pipes or wall sleeves (e.g. 15661) in concrete pools. All systems are compatible with Connect, Plug&Play and On/Off FlexiMini lamps.
Get a quote for LumiPlus FlexiMini Fixing Systems and Frames
We select equipment together based on pool volume, turnover time and plant-room conditions.
We bring filters, pumps, chemicals and accessories together in a single quote.
Our engineering team answers your questions on model selection, capacity and compatibility.
We support you through installation, commissioning and periodic maintenance.
