Heat Pumps and Heating
Zodiac RE/U is a digitally controlled electric pool heater rated 12–18 kW with two-stage power management. With titanium heating elements, a ±0.5 °C precision thermostat, flow sensor and safety limit, it delivers rapid temperature rise in large pools and runs on 230 V single-phase or 400 V three-phase.
RE/U 12M · 12 kW (6+6) · 230 V single-phase
Birden fazla ürünü listenize ekleyip hepsi için tek seferde teklif isteyebilirsiniz. Tek ürün için hemen teklif isteyin.
| Type | Electric pool heater, in-line, modular |
|---|---|
| Output | 12 – 18 kW, two-stage |
| Recommended flow | 5 – 22 m³/h |
| Power supply | 230 V single-phase (M) / 400 V three-phase (T) |
| Heating element | Titanium |
| Thermostat | Digital, ±0.5 °C · timer |
| Connection | PVC Ø63 (outside) / Ø50 (inside), in-line |
| Weight | 12 kg |
| Warranty / origin | 2 years · France |
Values by order code
| Order code | ||||
|---|---|---|---|---|
| Recommended water flow (m³/h) | 5 – 22 | 5 – 22 | 5 – 22 | 5 – 22 |
| Power supply | 220-240 V / 1 / 50-60 Hz | 380-400 V / 3 / 50-60 Hz | 220-240 V / 1 / 50-60 Hz | 380-400 V / 3 / 50-60 Hz |
| Max. operating current (A) | 53 | 22 | 66 | 26 |
| Recommended supply cable section (mm²) | 3 × 16 | 5 × 6 | 3 × 16 | 5 × 6 |
| Weight (kg) | 12 | 12 | 12 | 12 |
| Order code | Variant description | Certifications |
|---|---|---|
| W40TIT12M | RE/U 12M · 12 kW (6+6) · 230 V single-phase | — |
| W40TIT15 | RE/U 15T · 15 kW · 400 V three-phase | — |
| W40TIT15M | RE/U 15M · 15 kW (6+9) · 230 V single-phase | — |
| W40TIT18 | RE/U 18T · 18 kW (9+9) · 400 V three-phase | — |
Zodiac RE/U is a digitally controlled electric pool heater rated 12–18 kW with two-stage power management. With titanium heating elements, a ±0.5 °C precision thermostat, flow sensor and safety limit, it delivers rapid temperature rise in large pools and runs on 230 V single-phase or 400 V three-phase.
RE/U is a compact, standalone electric heater that is easy to install and use, fitted in-line on the filtration system; it heats the pool quickly and keeps the water at the desired temperature. With two-stage power management and a modular design it is the most powerful model in the Zodiac electric heater range and is recommended for large pools.
A control panel with ±0.5 °C precision thermostat, digital display and timer, LCD screen, lighted control buttons and indicators, power contactor and flow sensor are standard. A positive-safety high-temperature cut-out, an EPDM-sealed watertight pin and Hypalon electrical connections ensure safe operation.
All Zodiac electric heaters are fitted with titanium heating elements, which makes them highly durable. It installs in-line with a Ø63 (outside) or Ø50 (inside) PVC water connection and supports either flow direction; simply reverse the flow sensor, control and safety sensors. Made in France with a 2-year warranty.
