Pool Pumps
AstralPool Maxim is a centrifugal pool pump with a plastic body, AISI-316 stainless steel shaft and an 8-litre pre-filter basket. Running at 2860 rpm, its 3.5–5.5 HP three-phase models deliver 56–88 m³/h at 8 m, self-prime up to 1.5 m and have a 3" threaded connection and an IE2-efficiency motor.
3.5 HP · three-phase 230/400 V · 3" threaded connection · GS, IE2
Birden fazla ürünü listenize ekleyip hepsi için tek seferde teklif isteyebilirsiniz. Tek ürün için hemen teklif isteyin.
| Pump type | Centrifugal with pre-filter, self-priming (up to 1.5 m) |
|---|---|
| Body / shaft | Plastic body / AISI-316 stainless shaft |
| Power | 3.5 / 4.5 / 5.5 HP |
| Power supply | 230/400 V three-phase |
| Speed | 2860 rpm |
| Flow (at 8 m) | 56 / 74 / 88 m³/h |
| Pre-filter | 8 L basket, transparent lid |
| Connection | 3" threaded |
| Motor efficiency | IE2 |
Values by order code
| Order code | |||
|---|---|---|---|
| Flow at 8 m (m³/h) | 56 | 74 | 88 |
| Flow at 10 m (m³/h) | 50 | 66 | 78 |
| Flow at 12 m (m³/h) | 42 | 57 | 67 |
| Flow at 14 m (m³/h) | 34 | 46 | 53 |
| Flow at 16 m (m³/h) | 23 | 30 | 34 |
| Flow at 19.5 m (m³/h) | 0 | 0 | 0 |
| Weight (kg) | 32 | 34 | 37 |
| Order code | Variant description | Certifications |
|---|---|---|
| 08003 | 3.5 HP · three-phase 230/400 V · 3" threaded connection | GS, IE2 |
| 08004 | 4.5 HP · three-phase 230/400 V · 3" threaded connection | GS, IE2 |
| 08005 | 5.5 HP · three-phase 230/400 V · 3" threaded connection | GS, IE2 |
AstralPool Maxim is a centrifugal pool pump with a plastic body, AISI-316 stainless steel shaft and an 8-litre pre-filter basket. Running at 2860 rpm, its 3.5–5.5 HP three-phase models deliver 56–88 m³/h at 8 m, self-prime up to 1.5 m and have a 3" threaded connection and an IE2-efficiency motor.
Maxim's pump body is made of plastic and the pump shaft of AISI-316 stainless steel. The pre-filter basket holds 8 litres and the pre-filter lid is transparent, so basket fill can be checked without opening the lid.
The pump self-primes up to 1.5 m and runs at 2860 rpm. The three-phase (230/400 V) models at 3.5, 4.5 and 5.5 HP have a 3" threaded connection and an IE2 high-efficiency motor.
At 8 m head the 3.5 HP model delivers 56 m³/h, the 4.5 HP model 74 m³/h and the 5.5 HP model 88 m³/h, enabling high-flow filtration with a single pump in large residential, hotel and public pools.
