Pool Pumps
AstralPool Aral Plus C-3000 is a cast iron centrifugal pump with pre-filter and a 2-pole motor running at 3000 rpm, designed for public pools. Its 3–12.5 HP models deliver 42–163 m³/h at 10 m head; it has a bronze impeller, cataphoresis-coated wetted parts and CE marking.
3 HP · three-phase 230/400 V · suction DN80 / discharge 3" BSP · CE
Birden fazla ürünü listenize ekleyip hepsi için tek seferde teklif isteyebilirsiniz. Tek ürün için hemen teklif isteyin.
| Pump type | Centrifugal with pre-filter, cast iron body |
|---|---|
| Motor | 2-pole, 3000 rpm |
| Power | 3 – 12.5 HP (2.2 – 9.2 kW) |
| Power supply | 230/400 V or 400/690 V three-phase, 50 Hz |
| Impeller | Bronze |
| Surface protection | Cataphoresis coating on wetted parts |
| Flow (at 10 m) | 42 – 163 m³/h |
| Connections | Suction DN80–DN125, discharge 3" BSP / DN100 |
| Conformity | CE |
Values by order code
| Order code | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Motor power | 2,20 kW (3 HP) | 3 kW (4 HP) | 3 kW (4 HP) | 4 kW (5,5 HP) | 4 kW (5,5 HP) | 4 kW (5,5 HP) | 4 kW (5,5 HP) | 5,5 kW (7,5 HP) | 5,5 kW (7,5 HP) | 7,5 kW (10 HP) | 9,2 kW (12,5 HP) |
| Current, low / high voltage (A) | 7,6 / 4,3 | 9,9 / 5,7 | 5,7 / 3,3 | 13,0 / 7,4 | 7,4 / 4,3 | 13,0 / 7,4 | 7,4 / 4,3 | 17,6 / 10,1 | 10,1 / 5,9 | 13,5 / 7,8 | 16,6 / 9,6 |
| Suction connection (DN) | 80 | 100 | 100 | 100 | 100 | 125 | 125 | 125 | 125 | 125 | 125 |
| Discharge connection (DN) | 3" BSP | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| Flow at 6 m (m³/h) | 51 | 118 | 118 | 106 | 106 | 152 | 152 | 152 | 152 | 185 | 194 |
| Flow at 8 m (m³/h) | 47 | 105 | 105 | 99 | 99 | 130 | 130 | 136 | 136 | 172 | 179 |
| Flow at 10 m (m³/h) | 42 | 85.8 | 85.8 | 85 | 85 | 110 | 110 | 123 | 123 | 158 | 163 |
| Flow at 12 m (m³/h) | 38 | 70 | 70 | 76 | 76 | 81 | 81 | 106 | 106 | 143 | 147 |
| Flow at 14 m (m³/h) | 27 | 49 | 49 | 58 | 58 | 55 | 55 | 81 | 81 | 126 | 129 |
| Flow at 16 m (m³/h) | 8 | 20 | 20 | 41 | 41 | – | – | 55 | 55 | 106 | 109 |
| Flow at 18 m (m³/h) | – | – | – | – | – | – | – | 5 | 5 | 82 | 87 |
| Flow at 20 m (m³/h) | – | – | – | – | – | – | – | – | – | 43 | 61 |
| Flow at 22 m (m³/h) | – | – | – | – | – | – | – | – | – | – | 26 |
| Weight (kg) | 55 | 68 | 68 | 77 | 77 | 90 | 90 | 99 | 99 | 104 | 113 |
| Order code | Variant description | Certifications |
|---|---|---|
| 76917 | 3 HP · three-phase 230/400 V · suction DN80 / discharge 3" BSP | CE |
| 76918 | 4 HP · three-phase 230/400 V · suction DN100 / discharge DN100 | CE |
| 76919 | 4 HP · three-phase 400/690 V · suction DN100 / discharge DN100 | CE |
| 76920 | 5.5 HP · three-phase 230/400 V · suction DN100 / discharge DN100 | CE |
| 76921 | 5.5 HP · three-phase 400/690 V · suction DN100 / discharge DN100 | CE |
| 76922 | 5.5 HP · three-phase 230/400 V · suction DN125 / discharge DN100 | CE |
| 76923 | 5.5 HP · three-phase 400/690 V · suction DN125 / discharge DN100 | CE |
| 76924 | 7.5 HP · three-phase 230/400 V · suction DN125 / discharge DN100 | CE |
| 76925 | 7.5 HP · three-phase 400/690 V · suction DN125 / discharge DN100 | CE |
| 76926 | 10 HP · three-phase 400/690 V · suction DN125 / discharge DN100 | CE |
| 76927 | 12.5 HP · three-phase 400/690 V · suction DN125 / discharge DN100 | CE |
AstralPool Aral Plus C-3000 is a cast iron centrifugal pump with pre-filter and a 2-pole motor running at 3000 rpm, designed for public pools. Its 3–12.5 HP models deliver 42–163 m³/h at 10 m head; it has a bronze impeller, cataphoresis-coated wetted parts and CE marking.
The Aral Plus C-3000 pump series is made of cast iron and specially designed for public pools. It features a standard 2-pole motor design running at 3000 rpm up to 12.5 HP.
The bronze impeller and all components in contact with water undergo cataphoresis treatment. This provides robust protection against corrosion and oxidation, significantly extending pump life and ensuring durability and consistent performance over time.
The series comes in 230/400 V and 400/690 V three-phase models from 3 HP to 12.5 HP. Models from 4 HP upwards have a DN100 or DN125 flanged suction and DN100 discharge; the 3 HP model has a DN80 suction and 3" BSP discharge.
