Pool Pumps
AstralPool Aral Plus C-1500 is a cast iron centrifugal pump with pre-filter and a 4-pole motor running at 1450 rpm, designed for large public pools. Its 4–25 HP models deliver 55–369 m³/h at 10 m head; it runs quietly, is cataphoresis-coated and has a bronze impeller option.
4 HP · three-phase 230/400 V · suction DN100 / discharge DN80 · CE
Birden fazla ürünü listenize ekleyip hepsi için tek seferde teklif isteyebilirsiniz. Tek ürün için hemen teklif isteyin.
| Pump type | Centrifugal with pre-filter, cast iron body |
|---|---|
| Motor | 4-pole, 1450 rpm |
| Power | 4 – 25 HP (3 – 18.5 kW) |
| Power supply | 230/400 V or 400/690 V three-phase, 50 Hz |
| Surface protection | Cataphoresis coating on wetted parts |
| Impeller | Standard; bronze impeller optional |
| Flow (at 10 m) | 55 – 369 m³/h |
| Connections | Suction DN100–DN200, discharge DN80–DN125 |
| Conformity | CE |
Values by order code
| Order code | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Motor power | 3 kW (4 HP) | 3 kW (4 HP) | 4 kW (5,5 HP) | 4 kW (5,5 HP) | 5,5 kW (7,5 HP) | 5,5 kW (7,5 HP) | 7,5 kW (10 HP) | 9,2 kW (12,5 HP) | 11 kW (15 HP) | 15 kW (20 HP) | 18,5 kW (25 HP) |
| Current, low / high voltage (A) | 10,5 / 6 | 6,1 / 3,5 | 13,8 / 7,9 | 7,9 / 4,6 | 18,6 / 10,7 | 10,7 / 6,2 | 14,3 / 8,3 | 17,5 / 10,1 | 20,4 / 11,8 | 27,3 / 15,8 | 33,5 / 19,4 |
| Suction connection (DN) | 100 | 100 | 100 | 100 | 125 | 125 | 125 | 150 | 150 | 200 | 200 |
| Discharge connection (DN) | 80 | 80 | 80 | 80 | 100 | 100 | 100 | 100 | 100 | 125 | 125 |
| Flow at 6 m (m³/h) | 73 | 73 | 99 | 99 | 140 | 140 | 156 | 199 | – | – | – |
| Flow at 8 m (m³/h) | 66 | 66 | 91 | 91 | 128 | 128 | 145 | 185 | – | 299 | – |
| Flow at 10 m (m³/h) | 55 | 55 | 82 | 82 | 114 | 114 | 131 | 170 | 175 | 287 | 369 |
| Flow at 12 m (m³/h) | 46 | 46 | 70 | 70 | 97 | 97 | 117 | 154 | 163 | 260 | 349 |
| Flow at 14 m (m³/h) | 33 | 33 | 58 | 58 | 67 | 67 | 97 | 131 | 146 | 222 | 324 |
| Flow at 16 m (m³/h) | 11 | 11 | 42 | 42 | 23 | 23 | 73 | 112 | 125 | 175 | 293 |
| Flow at 18 m (m³/h) | – | – | 19 | 19 | – | – | 13 | 77 | 102 | – | 244 |
| Flow at 20 m (m³/h) | – | – | – | – | – | – | – | – | 73 | – | 184 |
| Flow at 22 m (m³/h) | – | – | – | – | – | – | – | – | – | – | 101 |
| Weight (kg) | 103 | 103 | 111 | 111 | 143 | 143 | 153 | 213 | 243 | 298 | 314 |
| Order code | Variant description | Certifications |
|---|---|---|
| 76906 | 4 HP · three-phase 230/400 V · suction DN100 / discharge DN80 | CE |
| 76907 | 4 HP · three-phase 400/690 V · suction DN100 / discharge DN80 | CE |
| 76908 | 5.5 HP · three-phase 230/400 V · suction DN100 / discharge DN80 | CE |
| 76909 | 5.5 HP · three-phase 400/690 V · suction DN100 / discharge DN80 | CE |
| 76910 | 7.5 HP · three-phase 230/400 V · suction DN125 / discharge DN100 | CE |
| 76911 | 7.5 HP · three-phase 400/690 V · suction DN125 / discharge DN100 | CE |
| 76912 | 10 HP · three-phase 400/690 V · suction DN125 / discharge DN100 | CE |
| 76913 | 12.5 HP · three-phase 400/690 V · suction DN150 / discharge DN100 | CE |
| 76914 | 15 HP · three-phase 400/690 V · suction DN150 / discharge DN100 | CE |
| 76915 | 20 HP · three-phase 400/690 V · suction DN200 / discharge DN125 | CE |
| 76916 | 25 HP · three-phase 400/690 V · suction DN200 / discharge DN125 | CE |
AstralPool Aral Plus C-1500 is a cast iron centrifugal pump with pre-filter and a 4-pole motor running at 1450 rpm, designed for large public pools. Its 4–25 HP models deliver 55–369 m³/h at 10 m head; it runs quietly, is cataphoresis-coated and has a bronze impeller option.
Aral Plus C-1500 is made of cast iron and specially designed for public pools. Its four-pole, 1450 rpm motor of up to 25 HP is carefully engineered for high performance, delivering the large flows that are ideal for big pools while keeping noise low in operation.
All components in contact with water undergo cataphoresis treatment, which provides robust protection against corrosion and oxidation, ensures durability and consistent performance over time and significantly extends pump life.
A bronze impeller option is also available. The series comes in 230/400 V and 400/690 V three-phase models from 4 HP to 25 HP, with DN100–DN200 suction and DN80–DN125 discharge connections depending on power.
Get a quote for Aral Plus C-1500 Cast Iron Centrifugal Pump
We select equipment together based on pool volume, turnover time and plant-room conditions.
We bring filters, pumps, chemicals and accessories together in a single quote.
Our engineering team answers your questions on model selection, capacity and compatibility.
We support you through installation, commissioning and periodic maintenance.
