The Viridis Social Facility Pool in Cengelkoy, Istanbul was developed to serve a high-density residential community with exceptional water hygiene, user comfort, and long-term durability.
Designed to meet rigorous Turkish and European public pool health standards, the facility incorporates dual multi-layer quartz sand filters, high-output circulation pumps, and a complete overflow surge gutter system.
Artemis Pool managed the hydraulic sizing, balance tank construction, waterproofing, porcelain tiling, and automated chemical control systems from concept to commissioning.
5 Stages
Execution Process
6 Images
Project Gallery
0 Specs
Technical Details
5 Notes
Engineering Notes
High-occupancy residential pool systems require robust hydraulic distribution to eliminate dead zones, rapid turnover rates to maintain disinfectant residuals, and heavy-duty non-slip surround surfacing for maximum bather safety.
After
BeforeDrag slider to compare before and after
Precision screed leveling and hydraulic penetrations in Cengelkoy.
The concrete structure was thoroughly cleaned and inspected for micro-cracks before high-strength polymer-modified leveling screeds were installed to establish precise floor slopes.
All PVC wall and floor inlets, vacuum points, and main drains were pressure-tested at 6 bar prior to final screeding.
Application of flexible cementitious membrane with reinforcing bands.
Two coats of flexible cementitious waterproofing were applied across the main pool basin, perimeter overflow gutters, and balance surge tank.
Elastomeric sealing tapes were vulcanized at all structural cold joints to ensure lifelong leak-free containment.
Commercial quartz sand filter units with multi-port valves and PN16 manifolding.
We installed dual commercial polyester-reinforced sand filters packed with graded quartz silica media (0.4-0.8mm and 1.0-2.0mm) for optimal turbidity removal.
Self-priming commercial pumps provide a 4-hour total pool volume turnover cycle, exceeding municipal public health mandates.
Automated amperometric chlorine and potentiometric pH control station.
An automated chemical controller continuously samples pool water, measuring pH, ORP, and temperature.
Peristaltic chemical pumps inject sanitizer and pH regulators proportionally into the return flow, preventing chemical spikes and maintaining optimal water balance at all times.
The Viridis Cengelkoy pool was commissioned successfully, delivering crystal-clear water and effortless automated maintenance for facility management.
Artemis Pool provided facility staff with operational training, digital chemical logs, and scheduled preventive maintenance coverage.
220 m³ pool basin with 4-hour hydraulic turnover rate
Dual commercial sand filters with graded media bed
Continuous overflow perimeter gutters with anti-vortex drain fittings
Automated amperometric and potentiometric chemical dosing system
Full compliance with TS EN 15288 swimming pool safety standards
