Salt Chlorinators
Zodiac eXPERT is a versatile salt chlorinator producing 7–40 g/h of chlorine for pools up to 180 m³. With a large touchscreen with big fonts, a waterproof IP65 control panel and, depending on the model, pH or pH/ORP regulation, it provides fully automatic water care; it can be controlled from the Fluidra Pool app with the optional iQBridge RS.
eXPERT 7 · 7 g/h · 30 m³ · standard
Birden fazla ürünü listenize ekleyip hepsi için tek seferde teklif isteyebilirsiniz. Tek ürün için hemen teklif isteyin.
| Chlorine production | 7 / 12 / 21 / 30 / 40 g/h |
|---|---|
| Pool volume | 30 / 50 / 100 / 140 / 180 m³ |
| Salinity | Recommended 4 g/L (min. 3.5 g/L) |
| Cell life | 10,000 h |
| Cell type | SC6 ruthenium-coated titanium electrodes |
| Cell position | Vertical |
| Polarity reversal | 2, 3, 4 or 7 h (factory 2 h) |
| Operating modes | Normal, Boost (100%, 24 h), Low (10–90%) |
| Measuring range | 0.0–9.9 pH (0.1) · 0–999 mV (1 mV) |
| Dosing pump | Peristaltic pH pump, 1.5 l/h |
| Connectivity / app | Optional iQBridge RS + Fluidra Pool |
| Pipe connection | DN50 / DN63 |
| Water temperature | 5–40 °C |
| Power supply | 220–240 V / 50–60 Hz |
| Cell dimensions | 33 × 16 × 17 cm |
| Control unit dimensions | 23 × 34 × 12 cm |
| Protection class | IP65 |
| Warranty | 2 years |
Values by model
| Model | |||||
|---|---|---|---|---|---|
| Chlorine output (g/h) | 7 | 12 | 21 | 30 | 40 |
| Recommended pool volume (m³) | 30 | 50 | 100 | 140 | 180 |
| Code – standard | 74183 | 74184 | 74185 | 74186 | 74187 |
| Code – pH | 74188 | 74189 | 74190 | 74191 | 74192 |
| Code – pH/ORP | 74193 | 74194 | 74195 | 74196 | 74197 |
| Order code | Variant description | Certifications |
|---|---|---|
| 74183 | eXPERT 7 · 7 g/h · 30 m³ · standard | — |
| 74184 | eXPERT 12 · 12 g/h · 50 m³ · standard | — |
| 74185 | eXPERT 21 · 21 g/h · 100 m³ · standard | — |
| 74186 | eXPERT 30 · 30 g/h · 140 m³ · standard | — |
| 74187 | eXPERT 40 · 40 g/h · 180 m³ · standard | — |
| 74188 | eXPERT 7 pH · 7 g/h · 30 m³ · with pH control | — |
| 74189 | eXPERT 12 pH · 12 g/h · 50 m³ · with pH control | — |
| 74190 | eXPERT 21 pH · 21 g/h · 100 m³ · with pH control | — |
| 74191 | eXPERT 30 pH · 30 g/h · 140 m³ · with pH control | — |
| 74192 | eXPERT 40 pH · 40 g/h · 180 m³ · with pH control | — |
| 74193 | eXPERT 7 pH/ORP · 7 g/h · 30 m³ · with pH + ORP control | — |
| 74194 | eXPERT 12 pH/ORP · 12 g/h · 50 m³ · with pH + ORP control | — |
| 74195 | eXPERT 21 pH/ORP · 21 g/h · 100 m³ · with pH + ORP control | — |
| 74196 | eXPERT 30 pH/ORP · 30 g/h · 140 m³ · with pH + ORP control | — |
| 74197 | eXPERT 40 pH/ORP · 40 g/h · 180 m³ · with pH + ORP control | — |
| 75042 | iQBridge RS · Wi-Fi gateway | — |
Zodiac eXPERT is a versatile salt chlorinator producing 7–40 g/h of chlorine for pools up to 180 m³. With a large touchscreen with big fonts, a waterproof IP65 control panel and, depending on the model, pH or pH/ORP regulation, it provides fully automatic water care; it can be controlled from the Fluidra Pool app with the optional iQBridge RS.
eXPERT makes installation and adjustment easy thanks to its large touchscreen and big fonts, and its user-friendly information screen shows pool status at a glance. Its robust cell guarantees long-term water care; pH versions handle water balance, while pH/ORP versions also take over automatic chlorination.
It offers Normal, Boost (100% for 24 hours) and Low (cover adjustable 10–90%) modes, polarity reversal at 2, 3, 4 or 7 hours and control by the filtration timer. pH and pH/ORP versions include a pH dosing pump kit and sensor kits with calibration solutions; factory settings are pH 7.2 / ORP 700 mV. All eXPERT models produced from 2023 have a dedicated jack input for the iQBridge RS (75042).
